0.44mm nickel-plated copper stranded wire

DescriptionItemStandard diameter (mm)0.05≤d≤0.090.09<d≤0.250.25<d≤0.5Tolerance (mm)±0.003±0.004±0.005Resistance (Ωmm²)≤0.01851≤0.01802≤0.0177Elongation (%)*≥6≥12≥15       Number of stranded wires*       7-100Directionright

Featured Products


0.44mm Nickel Plated Copper Wire Stranded Wire0.44mm Nickel Plated Copper Wire Stranded Wire0.44mm Nickel Plated Copper Wire Stranded Wire

0.44mm Nickel Plated Copper Wire Stranded Wire

Description

ItemStandard diameter (mm)
0.05≤d≤0.090.09<d≤0.250.25<d≤0.5
Tolerance (mm)±0.003±0.004±0.005
Resistance (Ωmm²)≤0.01851≤0.01802≤0.0177
Elongation (%)*≥6≥12≥15
       Number of stranded wires*       7-100
Directionright S or left Z
Pitch (mm)*2.0-100 mm
Tensile strength (Mpa)≥196
Plating layer (um)*0.3-2.0 um
ExteriorNo scratches, oil stains, copper exposure, oxidation, etc.
Packaging*                                    type 200/300/400 plastic reel; type 400/500 iron reel, etc.
NoteCustomization Available
