UL10070 PVC Insulated Wire-Rated temperature: 105ºC-Rated voltage: 600V-Reference Standard: UL758, UL1581, C22.2 No.210-Passes UL VW-1 & CSA FT1 vertical flame test.-Uniform insulation thickness of wire to ensure easy stripping and cutting.-For internal wiring of electronic and electrical equipment and appliance. C

Featured Products

UL10070 PVC Insulated Wire
-Rated temperature: 105ºC
-Rated voltage: 600V
-Reference Standard: UL758, UL1581, C22.2 No.210
-Passes UL VW-1 & CSA FT1 vertical flame test.
-Uniform insulation thickness of wire to ensure easy stripping and cutting.
-For internal wiring of electronic and electrical equipment and appliance.


ConductorInsulationMax. Cond Resistance at 20°C
(Ω/kft)
AWGConstruction
(No./mm)
Diameter
(mm)
Diameter
(mm)
187×9/0.1271.162.807.06
167×15/0.1271.493.104.45
147×24/0.1272.133.752.73
127×37/0.1272.674.301.72
107×59/0.1273.365.001.08
87×95/0.1274.306.700.6795
67×150/0.1275.418.650.4276
47×7×34/0.1276.8510.00.269
27×7×54/0.1278.6511.950.1691
17×7×68/0.1279.7014.00.134
1/07×7×86/0.12710.9115.20.1063
2/07×7×108/0.12712.2316.50.0843
3/019×7×51/0.12713.8518.20.0669
4/019×7×64/0.12715.5219.90.0525
